![Ore Dryer Ore Dryer](/uploads/20240419/6226d3db417433ba04c8cf51ecca3a62.jpg)
Ore dryers can be used to dry a variety of different ores,mineral ,including iron ore, copper ore, lead-zinc ore, gold ore, limestone,clay,etc. They are commonly used in mining operations, mineral processing plants and other industrial settings.
![Ore Dryer - 0 Ore Dryer - 0](/uploads/20240419/6226d3db417433ba04c8cf51ecca3a62.jpg)
![Ore Dryer - 1 Ore Dryer - 1](/uploads/20240708/6f5fa9ae9d67bc6b7b05ff2a68b3e011.jpg)
![Ore Dryer - 2 Ore Dryer - 2](/uploads/20240401/1450df0abf86a6ae1eed1666546458e4.jpg)
![Ore Dryer - 3 Ore Dryer - 3](/uploads/20230531/e7d30781ecd94ec384b8cd10ebe93a7c.jpg)
- Capacity:0.5-100t/h
- Power:3-185kw
- Input moisture:40%
- Output moisture:5%(adjustable)
- Applicable :Ore,slag,Carbide slag,mineral,limestone ,clay,kaolin,iron ore,bentonite
Product Introduction
Ore dryers can be used to dry a variety of different ores,mineral ,including iron ore, copper ore, lead-zinc ore, gold ore, limestone,clay,etc. They are commonly used in mining operations, mineral processing plants and other industrial settings.
Applicable Material
Ore dryers are widely used in building materials, metallurgy, chemical and cement industries to dry slag, ore,mineral,Bentonite,Kaolin,limestone, coal powder, slag, clay and other materials.
The heat sources of single-cylinder dryers are diverse and can be selected according to different application scenarios and material characteristics. Common heat source types include ordinary hot air, gas, electric heating, steam, biomass fuel, coal, etc.
![Ore Dryer Ore Dryer](/uploads/20231214/b7293eb757864ed455acc60f54928c94.jpg)
Product Features
- 01
-
High quality sheet, wear and durable
The dryer barrel is made of wear-resistant manganese plate, which has the characteristics of high hardness and high toughness; and its wear resistance is higher than other materials.
- 02
-
Upgraded version of internal structure, High thermal efficiency
The combination of the spiral guide plate and the new lifting plate increases the fluidity and heat conduction of the material, allowing the material to enter the drying barrel and form a material curtain, which is more adaptable to the moisture and viscosity of the material.
- 03
-
Energy saving, environmental protection and high efficiency
Enhanced dust removal device, a variety of heat sources to meet the environmental requirements of different areas.
- 04
-
Simple structure and stable performance
Adopting a new transmission system and upgraded reducer, it has strong power and more stable operation.Excellent structure, simple, stable operation, high degree of mechanization, large production capacity, continuous operation.
Working Principle
![Ore Dryer Ore Dryer](/assets/img/files/product/2- hong_gan/mei_ni_hong_gan_ji/2-2-3.jpg)
1.In the ore drying production line, the heat source equipment transfers heat energy to the drying equipment to heat it up. Subsequently, the feeding device sends the ore with high humidity into the drying equipment.
2.The high-temperature hot air generated by the hot air furnace fully contacts the ore, and the ore continuously rolls in the rotating drum, thereby accelerating the evaporation rate of water and achieving the drying effect.
- After a period of drying, the humidity of the ore will gradually decrease. When the required dryness is reached, the discharging device will send the dried ore out of the dryer. At the same time, the exhaust equipment will discharge the smoke and water vapor generated during the drying process out of the dryer to maintain a good ventilation environment inside the dryer.
4.The reasonable structural design of the supporting wheel and the diversified lubrication methods make the supporting wheel less prone to wear and shaft breakage, shorten the replacement cycle, and extend the service life of the supporting wheel.
5.The dryer system has good sealing performance,Inlet and outlet head adopts special seal to effectively reduce heat loss.
6.We accept customization of dryers made of different materials, such as carbon steel, stainless steel, special alloys, etc. Selection of dryer base, dust removal equipment, feeding and discharging equipment, and heat source equipment.
7.This dryer is suitable for a variety of heat sources:Fuel Oil、 Natural Gas/Propane、 Waste Heat、wood、coal、biomass pellets、electricity etc.
8.Provide product quality assurance, CE IOS certification,Factory price.
Technical Parameter
product standard(m) | Capacity(t/h) | Feed moisture(%) | Final Moisture(%) | Power(KW) |
---|---|---|---|---|
0.8*8 | 0.5-3 | 30% | 15%-1% | 3KW |
1*10 | 1-5 | 30% | 15%-1% | 5.5KW |
1.2*12 | 2-8 | 30% | 15%-1% | 11KW |
1.6*16 | 6-10 | 30% | 15%-1% | 15KW |
1.8*16 | 8-15 | 30% | 15%-1% | 18.5KW |
2*18 | 10-20 | 30% | 15%-1% | 22KW |
2.2*18 | 12-25 | 30% | 15%-1% | 30KW |
2.4*22 | 15-30 | 30% | 15%-1% | 45KW |
2.6*24 | 18-35 | 30% | 15%-1% | 55KW |
2.8*26 | 20-40 | 30% | 15%-1% | 75KW |
3*28 | 25-50 | 30% | 15%-1% | 90KW |
3.2*28 | 30-60 | 30% | 15%-1% | 110KW |
3.4*30 | 35-70 | 30% | 15%-1% | 132KW |
3.6*32 | 40-80 | 30% | 15%-1% | 160KW |
3.8*32 | 50-100 | 30% | 15%-1% | 185KW |
