Ore Slag dryer is a kind of equipment widely used in building materials, metallurgy, chemical industry, cement and other industries. It is mainly used to dry ore slag, fly ash, calcium carbide slag, limestone, clay, river sand, quartz sand, water slag and other materials. The slag dryer not only has a large processing capacity, but also has strong overload resistance and high thermal efficiency, which can significantly reduce drying costs.
![Ore Slag Rotary Dryer - 0 Ore Slag Rotary Dryer - 0](/assets/img/files/product/2- hong_gan/san_tong/3.png)
![Ore Slag Rotary Dryer - 1 Ore Slag Rotary Dryer - 1](/uploads/20240402/7ae579aa3f62694f47f91e712ebe6bca.jpg)
![Ore Slag Rotary Dryer - 2 Ore Slag Rotary Dryer - 2](/uploads/20240402/1511b0c846bfc1b58bb07947f3b23c8e.jpg)
![Ore Slag Rotary Dryer - 3 Ore Slag Rotary Dryer - 3](/uploads/20240402/cbbabd0e8a3c0f5a26f577cacb96baa7.jpg)
- Capacity:1-50t/h
- Power:4-75KW
- Input moisture:20%
- Output moisture:0.5%(adjustable)
Product Introduction
Ore Slag dryer is a kind of equipment widely used in building materials, metallurgy, chemical industry, cement and other industries. It is mainly used to dry ore slag, fly ash, calcium carbide slag, limestone, clay, river sand, quartz sand, water slag and other materials. The slag dryer not only has a large processing capacity, but also has strong overload resistance and high thermal efficiency, which can significantly reduce drying costs.
Applicable Material
Heat Source types include ordinary hot air, gas, electric heating, steam, biomass fuel, coal, etc.
![Ore Slag Rotary Dryer Ore Slag Rotary Dryer](/uploads/20231214/b7293eb757864ed455acc60f54928c94.jpg)
Ore Slag, fly ash, carbide slag, limestone, clay, river sand, quartz sand, water slag,Yellow sand, wood chips and other granular, good flow, non-viscous materials.
![Ore Slag Rotary Dryer Ore Slag Rotary Dryer](/uploads/20240312/0d819a5d0ca27daf6ac963ce4d83a4f3.jpg)
Product Features
- 01
-
High quality plate, wear resistant and durable
It is made of wear-resistant manganese plate, and the new alloy lifting plate device is used inside, which is wear-resistant and durable and has a long service life.
- 02
-
Upgraded version structure, high thermal efficiency
The angle of the new lifting plate device is also seriously designed according to the characteristics of the material, which can increase the heating area of the material, high thermal efficiency and better product quality.
- 03
-
Low heat loss
The dryer system has good sealing performance, lnlet and outlet head adopts special seal to effectively reduce heat loss.
- 04
-
Strong power, smooth operation
Adopt new transmission system, upgrade version reducer, strong power, more stable operation.
Working Principle
![Ore Slag Rotary Dryer Ore Slag Rotary Dryer](/uploads/20230609/cac32924db282061101af9950521b7ea.png)
1.The material first goes into the inside drum, because there are the spiral shape boards fixed in the drum, when the dryer make rotary working, the spiral shape board will stir the material and make the material do movement.
2.When the material reaches the right side of the drum, it will go into the second drum for further drying.
3.The same working principle, the material then goes into outside drum, during the drying working process, the material will make three times drying, so the material can be dried completely in this process.
Technical Parameter
Specifications and Models | Handling Capacity Drying Sand(t/h) | Finished Product Moisture(%) | Power(KW) |
KLF-TH1630 | 1-5 | <2±1 | 4 |
KLF-TH2240 | 6-8 | <2±1 | 4 |
KLF-TH2460 | 10-15 | <2±1 | 7.5 |
KLF-TH2660 | 15-20 | <2±1 | 15 |
KLF-TH2870 | 25-30 | <2±1 | 18.5 |
KLF-TH3080 | 30-40 | <2±1 | 22 |
KLF-TH3290 | 40-50 | <2±1 | 45 |
KLF-TH3390 | 50-60 | <2±1 | 55 |
KLF-TH3610 | 70-80 | <2±1 | 75 |
The above parameters are for reference only. For more details, please contact customer service |
