It is made up of main kiln body and supporting Drive set cooling pipe and supporting drive set, fuel system, electricity Control secondary air set, exhaust dust set and warm-up kiln body etc The machine has function like: give an alarm for over temperature, give an alarm for over loading, auto control for working temperature.
- Capacity：8-90t/h
- Power：5.5-110KW
- Input moisture：20%
- Output moisture：0.5%(adjustable)
Product Introduction
It is made up of main kiln body and supporting Drive set cooling pipe and supporting drive set, fuel system, electricity Control secondary air set, exhaust dust set and warm-up kiln body etc The machine has function like: give an alarm for over temperature, give an alarm for over loading, auto control for working temperature.
Applicable Material
Soybean residue, fermented soybean residue, soybean milk and soybean milk residue, bean curd residue, pea residue, soybean residue, soybean fiber and other feed grade soybean residue materials drying.
Product Features
- 01
-
High degree of mechanization, cost saving
The automatic production mode can realize the automatic production from heating, feeding, feeding, drying, discharging and other processes; Save labor cost.
- 02
-
The equipment has reasonable structure and stable performance
Simple operation, stable performance, can work continuously for 24 hours, less failure, low maintenance cost.
- 03
-
Internal structure upgrade to increase thermal efficiency
The special dispersing device is adopted inside. After entering the rotary drum, the feed is quickly dispersed and decomposed, which effectively increases the area of contact between the feed and hot air.
- 04
-
Multistage dust removal, clean production
The whole drying system is equipped with perfect exhaust gas treatment device. The exhaust gas discharged from the gas cylinder is sent to the dust collector and discharged to the local environmental protection standards after purification.
Working Principle
adopts direct flow type of heating with heat soure from firing unit. The material to be dried is pushed back immindiately by spiral board when enters the shell from feeding tank and feeding chute. Because the dryer is installed in slope, material flows to the back end under gravity and rotation force, meanwhile, it is lifted by board repeatedly and thrown down accordingly, which make the material form even curtain, and exchange heat sufficiently with inner the heat flow. In the end, water in the material is dried by repeatedly scattering.
Technical Parameter
| product standard（m) | Capacity（t/h) | Feed moisture（%） | Final Moisture(%) | Power(KW) |
|---|---|---|---|---|
| 0.8*8 | 0.5-3 | 30% | 15%-1% | 3KW |
| 1*10 | 1-5 | 30% | 15%-1% | 5.5KW |
| 1.2*12 | 2-8 | 30% | 15%-1% | 11KW |
| 1.6*16 | 6-10 | 30% | 15%-1% | 15KW |
| 1.8*16 | 8-15 | 30% | 15%-1% | 18.5KW |
| 2*18 | 10-20 | 30% | 15%-1% | 22KW |
| 2.2*18 | 12-25 | 30% | 15%-1% | 30KW |
| 2.4*22 | 15-30 | 30% | 15%-1% | 45KW |
| 2.6*24 | 18-35 | 30% | 15%-1% | 55KW |
| 2.8*26 | 20-40 | 30% | 15%-1% | 75KW |
| 3*28 | 25-50 | 30% | 15%-1% | 90KW |
| 3.2*28 | 30-60 | 30% | 15%-1% | 110KW |
| 3.4*30 | 35-70 | 30% | 15%-1% | 132KW |
| 3.6*32 | 40-80 | 30% | 15%-1% | 160KW |
| 3.8*32 | 50-100 | 30% | 15%-1% | 185KW |
